Calipers:
|
Info / Part Number:
|
|
Left Hand - Part No:
|
120-6816-RD
|
|
Right Hand - Part No:
|
120-6816-RD
|
|
Type:
|
Forged Dynalite
|
|
Finish Color:
|
Red Powder Coat
|
|
Piston Count:
|
4
|
|
Piston Area (In²):
|
4.80
|
|
Piston Type:
|
Stainless
|
|
Mount Type:
|
Lug
|
|
Brake Pad Plate:
|
7112
|
|
Brake Pad Area (In²):
|
6.36
|
|
Brake Pad Volume (In³):
|
2.1
|
|
Pad Compound:
|
BP-10
|
Forged Dynalite Caliper - Red Powder Coat
|
|
|
|
Rotors:
|
Info / Part Number:
|
|
Left Hand - Part No:
|
160-5840
|
|
Right Hand - Part No:
|
160-5840
|
|
Type:
|
Ultralite HP 30
|
|
Style:
|
Plain Face
|
|
Surface Finish:
|
Plain
|
|
Material:
|
Iron
|
|
Outside Diameter (In.):
|
11
|
|
Width (In.):
|
0.81
|
|
Vane Count:
|
30 V
|
|
Design Type:
|
ULHP
|
|
Bedded:
|
No
|
|
Dynamically Balanced:
|
No
|
Ultralite HP 30 - Iron - Plain
|
|
|
|
Rotor Hats:
|
Info / Part Number:
|
|
Hat - Part No:
|
|
|
Type:
|
|
|
Material:
|
|
|
Finish Color:
|
|
|
Hat Offset Dimension (In.):
|
|
|
Bolt Circle 1:
|
|
|
Bolt Circle 2:
|
|
|
Bolt Circle 3:
|
|
|
Stud Diameter - BC 1:
|
|
|
Stud Diameter - BC 2:
|
|
|
Stud Diameter - BC 3:
|
|
|
|
|
Hubs:
|
Info / Part Number:
|
|
Hub - Part No:
|
270-11032
|
|
Type:
|
Hub - Vented Rotor Offset
|
|
Material:
|
Aluminum
|
|
Finish Color:
|
Bare
|
|
Mount Style:
|
Adapter
|
|
Bolt Circle 1:
|
5 x 4.50
|
|
Bolt Circle 2:
|
5 x 4.75
|
|
Bolt Circle 3:
|
|
|
Stud Diameter - BC 1:
|
1/2-20
|
|
Stud Diameter - BC 2:
|
1/2-20
|
|
Stud Diameter - BC 3:
|
|
Hub - Vented Rotor Offset - Aluminum - Bare
|
|
