MasterCylinder No: 260-10922

Call (805) 388-1188
Proportioning Valve
Prod #: 260-10922
Price: $45.30

Master Cylinder Dimensions
Bore Size N-A
Area (in²)
Stroke
Volume (cu in)
Master Cylinder Description
Type
Outlets 0
Material Aluminum / Steel
Finish Clear Anodize
Reservoir
Res Type
Res Size (oz)
Res Size(cu in)
Rate 0 to 57%
UPC Number
UPC 889545066715
Product Documents
Product Data Sheet


Click To Download

Proportioning Valve - Product Summary

The new generation of adjustable proportioning valves combines the latest refinements to deliver precise pressure metering and strength from a compact forged billet design. Pressure adjustments range from 100-1000 PSI and provide for a maximum decrease of 57% in line pressure, the most of any available valve. Adjuster knob with fine thread tuning provides precise pressure adjustment. This adjustment lets you fine tune the front to rear braking balance by proportionally decreasing the rear brake line pressure. Valves weigh only 5.2 ounces and have two .25” side mounting holes spaced 1.00” apart. This valve varies from our standard Knob Style Proportioning valve, as the in and out ports are 3/8-24 inverted flare seats and do not require tube nut adapters to directly install 3/8 tubing with inverted flare 3/8-24 nuts.

Master Cylinder Dimensions

Additional Dimensions
Overall Length(in)
Flange to End Length (in)
Inlet Size (in) 3/8-24 IF
Inlet Fit (in)
Outlet Size 1 (in) 3/8-24 IF
Outlet Fit 1 (in)
Outlet Size 2 (in)
Outlet Fit 2 (in)
Additional Notes
