1971-1987 Chevrolet C10 / GMC C15 Chevrolet C10 ProSpindles
Call (805) 388-1188
Spindle – Part No: 831-14202
Prod #: 831-14202
Price: $755.99
Spindle – 831-14202

Wilwood 1971-1987 Chevrolet C10 / GMC C15 Chevrolet C10 ProSpindles Wilwood 1971-1987 Chevrolet C10 / GMC C15 Chevrolet C10 ProSpindles Zoom Image

Product Description
Spindle Style: Drop
Material: Forged Aluminum
Finish: Black E-Coat
Spindle Description
Drop Dim: 2.5 Inch
Side: LH & RH
Weight (lbs): 43.0
Chevrolet C10 ProSpindles - Product Summary
1971-1987 Chevrolet C10 / GMC C15
UPC Number
UPC 889545077070
Cautionary Info
Spindles & Steering Arms (Pair) L/H & R/H
Can only be used with Wilwood Brake Kits
Product Documents
Product Data Sheet

Click to View

Wilwood’s ProSpindle Kits contain a pair of Modular Spindles, steering arms and hubs assemblies for either 63-70 or 71-87 Chevrolet & GMC 2WD C10/C15 Pickups and Suburban’s. Specifically designed for use with Wilwood’s disc brake kits, with a 2.50” drop for a more aggressive stance without affecting steering geometry. Constructed from a proprietary grade of forged aluminum with an integrated modular bearing hub assembly that supports both 5 x 4.75” and 5 x 5.00” wheel bolt circles. Direct mounting for radial caliper brackets create strong, zero flex platform for brake mounting.


Spindle Dimensions

1971-1987 Chevrolet C10 / GMC C15 Drawing 1971-1987 Chevrolet C10 / GMC C15 Drawing Zoom Image
Additional Spindle Dimensions
Mount Length (in)
Spindle 1 Length (in)
Spindle 2 Length (in)
Additional Notes
