Rotors:
|
Info / Part Number:
|
|
Left Hand - Part No:
|
160-8403
|
|
Right Hand - Part No:
|
160-8402
|
|
Type:
|
GT 72 Curved Vane
|
|
Style:
|
GT Slotted
|
|
Surface Finish:
|
Plain
|
|
Material:
|
Spec-37 Iron
|
|
Outside Diameter (In.):
|
14
|
|
Width (In.):
|
1.1
|
|
Vane Count:
|
72 CV
|
|
Design Type:
|
GT
|
|
Bedded:
|
No
|
|
Dynamically Balanced:
|
Yes
|
GT 72 Curved Vane - Spec-37 Iron - Plain
|
|
|
|
Rotor Hats:
|
Info / Part Number:
|
|
Hat - Part No:
|
170-10489
|
|
Type:
|
Big Brake Hat - Flared Bell
|
|
Material:
|
Aluminum
|
|
Finish Color:
|
Black E-Coat
|
|
Hat Offset Dimension (In.):
|
1.62
|
|
Bolt Circle 1:
|
5 x 4.50
|
|
Bolt Circle 2:
|
5 x 4.75
|
|
Bolt Circle 3:
|
|
|
Stud Diameter - BC 1:
|
0.52
|
|
Stud Diameter - BC 2:
|
0.52
|
|
Stud Diameter - BC 3:
|
0
|
Big Brake Hat - Flared Bell - Aluminum - Black E-Coat
|
|
|
|
Hubs:
|
Info / Part Number:
|
|
Hub - Part No:
|
270-10494
|
|
Type:
|
Hub - Hat Mount
|
|
Material:
|
Aluminum
|
|
Finish Color:
|
Bare
|
|
Mount Style:
|
Hat
|
|
Bolt Circle 1:
|
5 x 4.50
|
|
Bolt Circle 2:
|
5 x 4.75
|
|
Bolt Circle 3:
|
|
|
Stud Diameter - BC 1:
|
1/2-20
|
|
Stud Diameter - BC 2:
|
1/2-20
|
|
Stud Diameter - BC 3:
|
|
Hub - Hat Mount - Aluminum - Bare
|
|
